VT-350

Mass production vertical TC

• High-performance spindle: 2,500rpm(18.5/15kW)
• Highly rigid box way guide surface design
• Turret indexing time (1 face): 0.4secs
• Rapid feed (X/Z): 20/20m/min
• Various optional functions available; easy to maintain

Benefits

• High-performance spindle
The spindle in VT-350 provides powerful chucking for stable, precise machining. The Hwacheon clean room assembly facility, where these super-precision, super-speed spindles are manufactured, maintains optimal temperature and humidity, and is kept free of any foreign substances. Only the most skilled master engineers are allowed in the assembly facility, to produce only the best equipment under the toughest quality standard in the industry.

• High-performance turret tool post
VT-350’s turret is precise and durable even at high speed indexing, and offers outstanding performance at hard turning.
Turret type: hydraulic motor
Number of tool stations: 8 standard, 10 optional
Tool size: □ 25 ×Ø40
Turret indexing time (1 face): 0.34 secs
Chip-to-chip(100mm): 2 secs
Turret clamping force: 6,200 Kgf

• High-precision feed shaft
X axis: 1.6kW(2.2HP)
Rapid feedrate (X/Z): 20/20m/min
X/Z-axis guide ways: turcite box way design

• Enhance your productivity
One operator for two stations
The distance the operator has to travel in between the machines have been reduced to less than a third in comparison to the competitors’

Specs

Process Data
